Details
10 YEARS IN THE LEAD
10 years ago, we launched a bike that kickstarted a revolution in the design and construction of the performance road bike. The Teammachine SLR, has won every major title that a bike can win including; Monuments, World Championships, Olympic Games, and the Tour de France.
Using the combined knowledge from the past decade, we've changed the game again to deliver an all-new, class-leading frameset ready to lead for another 10 years.
ACCELERATED COMPOSITES EVOLUTION TECHNOLOGIE + (ACE+)
ACE+ not only runs through thousands of virtual prototypes using Stiffness, Weight, and Compliance as key influencers, but now includes a fourth key factor in the prototyping, Aerodynamics.
D-SHAPE SEAT POST
Improved seatpost design removing any excess materials, providing aerodynamic benefits and extra compliance.
BOTTOM BRACKET AND TORSIONAL STIFFNESS
Renowned for its power transfer, the new Teammachine SLR goes one step further with a wider bottom bracket contact area provided by the new downtube shape and the optimized carbon layup.
FORK PROFILE
An aerodynamically reshaped fork with stealth dropout design and integrated thru-axle nut show that high technical proficiency can go hand in hand with beautiful, minimalist aesthetics.
AEROCORE DESIGN
Our Aerocore system consists of two superlight carbon cages that seamlessly integrate into the reshaped downtube and seat tube, resulting in significant drag reduction when used with bottles.
COMFORT IS SPEED
The new Teammachine SLR is more compliant than ever, thanks to the latest evolution of the Tuned Compliance Concept (TCC) technology. Fine-tuning of the carbon layups, essential vertical frame, and seatpost flex, to improve traction and control, resulting in reduced muscle fatigue.
INTEGRATED COCKPIT SYSTEM (ICS2)
All new ICS2, with significant weight savings, high stiffness, clean aesthetics, and integrated device mounts for the most popular devices.
SIZE | 47 | 51 | 54 | 56 | 58 | 61 |
---|---|---|---|---|---|---|
Rider Height CM | <166 | 166-174 | 172-180 | 178-186 | 184-192 | >190 |
Top Tube MM (tt) | 517 | 534 | 594 | 559 | 574 | 589 |
Wheelbase MM (wb) | 968 | 986 | 989 | 1000 | 1015 | 1030 |
Seat Tube Angle (sa) | 73.5 | 73.5 | 73.5 | 73.5 | 73.5 | 73.5 |
Seatpost Length MM | 330 | 380 | 380 | 380 | 380 | 380 |
Stack MM | 506 | 530 | 550 | 565 | 584 | 608 |
Trail MM (trail) | 63 | 63 | 63 | 63 | 63 | 63 |
Rear Center MM (rc) | 410 | 410 | 410 | 410 | 410 | 410 |
Reach MM (reach) | 367 | 377 | 386 | 392 | 401 | 409 |
Head Tube MM (ht) | 110 | 130 | 145 | 165 | 184 | 210 |
Head Angle (ha) | 71.5 | 71.5 | 72.3 | 72.3 | 72.3 | 72.3 |
BB Drop MM (drop) | 69 | 69 | 69 | 69 | 69 | 69 |
Stem Length MM | 90 | 100 | 100 | 110 | 110 | 120 |
Seat Tube MM (st) | 423 | 468 | 504 | 524 | 545 | 574 |
Stem Angle | -12.5 | -12.5 | -12.5 | -12.5 | -12.5 | -12.5 |
Post Offset MM | 15 | 15 | 15 | 15 | 15 | 15 |
Crank Length MM | 170 | 170 | 172.5 | 172.5 | 175 | 175 |
Fork Rake MM (fr) | 48 | 48 | 43 | 43 | 43 | 43 |
Front Center MM (fc) | 568 | 586 | 589 | 599 | 614 | 630 |
Fork Length MM (fl) | 368 | 368 | 368 | 368 | 368 | 368 |
Bar Width MM | 400 | 420 | 420 | 420 | 420 | 420 |
Bar Reach MM | 67 | 67 | 67 | 67 | 67 | 67 |
Specs
Frame | Teammachine SLR 01 Premium Carbon with Aerocore Design |
---|---|
Fork | Teammachine SLR 01 Premium Carbon |
Wheels | Dura-Ace C50, 50mm carbon Disc |
Tires | Vittoria Corsa, 25mm |
Bottom Bracket | PF86 Bottom Bracket |
Crankset | SHIMANO Ultegra 12sp |
Chainrings | SHIMANO Ultegra 12sp |
Shifters | SHIMANO Ultegra Di2 12sp |
Front Derailleur | SHIMANO Ultegra Di2 12sp |
Rear Derailleur | SHIMANO Ultegra Di2 12sp |
Cassette/Freewheel | SHIMANO Ultegra 11-30T 12sp |
Chain | SHIMANO Ultegra 12sp |
Brakes | SHIMANO Ultegra, RT-MT800 Rotors (160/160) |
Handlebars | ICS Carbon, One-Piece Full Carbon Cockpit |
Stem | ICS Carbon, One-Piece Full Carbon Cockpit |
Seatpost | Teammachine SLR 01 Premium Carbon D-Shaped Seatpost, 15mm Offset |
Saddle | Selle Italia Flite Ti-316 Black/Red |
* Subject to change without notice.
Part Numbers
Option | MPN |
---|---|
White/Red Sram RED AXS / 54 | 84023 |
